| Clamping force |
kN |
1000 |
| Mold protection force |
kN |
- |
| Opening stroke |
mm |
640 |
| Min. mold height |
mm |
250 |
| Max. mold height |
mm |
- |
| Platen size (hor. x vert.) |
mm |
680x640 |
| Distance between tie bars |
mm |
480x440 |
| Max. mold weight |
kg |
- |
| Max. mold weight on the moving side |
kg |
- |
| Min. mold diameter |
mm |
Ø 315 |
| Centering ring injection side |
mm |
Ø 160 H7 |
| Centering ring ejector side |
mm |
Ø 160 H7 |
| Thread/depth in the clamping plates |
mm |
M16/40 |
| Ejector path |
mm |
125 |
| Ejector force |
kN |
27,5 |
| Screw diameter |
mm |
45C |
| Stroke volume |
ccm |
- |
| Ejecton weight (PS) |
g |
210 |
| Ejecton weight (PE) |
g |
164 |
| Max. dosage lenght |
mm |
220 |
| Specific injection pressure (při 400°C) |
bar |
1500 |
| Core puller |
|
1 |
