| Clamping force |
kN |
5000 |
| Mold protection force |
kN |
- |
| Opening stroke |
mm |
850 |
| Min. mold height |
mm |
400 |
| Max. mold height |
mm |
920 |
| Platen size (hor. x vert.) |
mm |
1300x1300 |
| Distance between tie bars |
mm |
920x920 |
| Max. mold weight |
kg |
8700 |
| Max. mold weight on the moving side |
kg |
5200 |
| Min. mold diameter |
mm |
- |
| Centering ring injection side |
mm |
Ø 200 H7 |
| Centering ring ejector side |
mm |
Ø 200 H7 |
| Thread/depth in the clamping plates |
mm |
M20/40 |
| Ejector path |
mm |
260 |
| Ejector force |
kN |
96 |
| Screw diameter |
mm |
80 |
| Stroke volume |
ccm |
1779 |
| Ejecton weight (PS) |
g |
- |
| Ejecton weight (PE) |
g |
- |
| Max. dosage lenght |
mm |
354 |
| Specific injection pressure (při 400°C) |
bar |
1855 |
| Core puller |
|
- |
